Description
Description
The 13th Gen Intel Core i9-13900 desktop processor employs innovative technologies such as Intel Adaptive Boost, Intel Thermal Velocity Boost, Intel Turbo Boost Max Technology 3.0, as well as support for PCIe 5.0 and 4.0, and is backward compatible with DDR5 and DDR4.
These 13th Gen processors are designed for gaming enthusiasts and professional creators, delivering exceptional performance, featuring integrated Intel UHD 770 graphics and incorporating a hybrid performance architecture that prioritizes and distributes workloads to optimize performance.
They are compatible with Intel 700 and Intel 600 series based motherboards, and feature a base processor power of 65W.
The 13th Gen Intel Core i9-13900 processor offers a total of 24 cores, with eight performance cores (P-cores) and 16 efficiency cores (E-cores), plus 32 threads. It also includes integrated Intel UHD Graphics 770.
Its hybrid performance architecture integrates two core microarchitectures, optimizing performance by prioritizing and distributing workloads. With a maximum speed of up to 5.6 GHz and a 36MB cache, it's compatible with motherboards based on the Intel 600 and 700 series chipsets.
Additionally, it features support for Turbo Boost Max Technology 3.0 and PCIe 5.0 and 4.0, as well as support for Intel Optane memory.
The i9-13900 is an attractive option for those looking for cutting-edge performance in their computing systems.
Technical Sheet
CPU specifications
Number of cores: 24
Number of Performance Cores: 8
Number of Efficient-cores: 16
Total threads: 32
Maximum turbo frequency: 5.60 GHz
Intel® Thermal Velocity Boost Frequency: 5.60 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency ‡: 5.50 GHz
Maximum turbo frequency of the Performance-core: 5.20 GHz
Efficient-core maximum turbo frequency: 4.20 GHz
Performance-core base frequency: 2.00 GHz
Efficient-core base frequency: 1.50 GHz
Cache: 36 MB Intel® Smart Cache
Total L2 Cache: 32 MB
Processor base power: 65 W
Maximum turbo power: 219 W
Additional information
Release date: Q1'23
Integrated options available: Yes
Terms of use: PC/Client/Tablet, Workstation
Memory specifications
Maximum memory size (depends on memory type): 192 GB
Memory types: Up to DDR5 5600 MT/s / Up to DDR4 3200 MT/s
Maximum number of memory channels: 2
Maximum memory bandwidth: 89.6 GB/s
ECC Memory Supported ‡: Yes
Technical Sheet
Specification | Detail |
---|---|
Total nuclei | 24 |
Performance Cores (P-cores) | 8 |
Efficient Cores (E-cores) | 16 |
Threads | 32 |
Maximum turbo frequency | 5.60 GHz |
Intel Thermal Velocity Boost Frequency | 5.60 GHz |
Turbo Boost Frequency Max 3.0 | 5.50 GHz |
P-core maximum turbo frequency | 5.20 GHz |
E-core maximum turbo frequency | 4.20 GHz |
P-core base frequency | 2.00 GHz |
E-core base frequency | 1.50 GHz |
L3 cache | 36 MB Intel Smart Cache |
Total L2 cache | 32 MB |
Base power | 65 W |
Maximum turbo power | 219 W |
Release date | Q1 2023 |
Integrated graphics | Intel UHD 770 |
Socket compatibility | Intel 600 and 700 series |
Supported memory types | DDR5 up to 5600 MT/s, DDR4 up to 3200 MT/s |
Maximum memory size | 192 GB |
Memory channels | 2 |
Memory bandwidth | 89.6 GB/s |
ECC memory support | Yeah |
PCI Express support | PCIe 5.0 and 4.0 |
